범용 스트레인게이지 (F 시리즈 포일)

범용 스트레인게이지 (F 시리즈 포일)

이 게이지는 그리드에 Cu-Ni 합금 호일을 사용하고 백킹에 특수 플라스틱을 사용합니다. -196 ~ + 150 ° C의 광범위한 작동 온도가 가능합니다. 뒷면은 자체 온도 보상을위한 목적 재료를 식별하기 위해 색상으로 구분됩니다. 일반적인 사용 게이지 외에 응력 집중 측정 및 잔류 응력 측정 용 스트레인 게이지를 사용할 수 있습니다. 리드 와이어 통합 스트레인 게이지는 다양한 유형의 리드 와이어와 함께 사용할 수 있습니다. 이 시리즈의 스트레인 게이지는 무연 솔더를 사용하는 옵션 –F와 함께 제공 될 수 있습니다. (이 시리즈의 GOBLET 게이지는 표준 사양으로 무연 솔더를 사용합니다.
  • 상세 설명
적용 표본​
금속, 세라믹, 합성물
작동 온도
-196 to +150℃
온도 보상 범위
+10 to +100℃
적용 가능한 접착제
CN, P-2, EB-2
Backing 재질
특수 플라스틱
ElementCu-Ni
변형 한계
5% (50000 x 10-6 strain)
실온에서의 피로 수명
1 x 106 (±1500 x 10-6 strain)

  • For general measurement  Single-element / two-element / three-element

     Single-element (G.F. 2.1 approx.)

    Gauge patternTypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    (mm)    		Backing
    width
    (mm)    		Resistance (Ω)
    flg_111FLG-02-11
    FLG-02-17
    FLG-02-23    		0.21.43.52.5120
    FLG-1-11
    FLG-1-17
    FLG-1-23    		11.16.52.5120
    fla_311FLA-03-11
    FLA-03-17
    FLA-03-23    		0.31.432.0120
    FLA-05-11
    FLA-05-17
    FLA-05-23    		0.51.252.2120
    FLA-1-11
    FLA-1-17
    FLA-1-23    		11.352.5120
    FLA-1-350-11
    FLA-1-350-17
    FLA-1-350-23    		124.73.6350
    FLA-2-11
    FLA-2-17
    FLA-2-23    		21.56.53120
    FLA-2-350-11
    FLA-2-350-17
    FLA-2-350-23    		21.96.13.5350
    FLA-3-11
    FLA-3-17
    FLA-3-23    		31.78.83.5120
    FLA-3-60-11
    FLA-3-60-17
    FLA-3-60-23    		31.28360
    FLA-3-350-11
    FLA-3-350-17
    FLA-3-350-23    		33.28.55350
    FLA-5-11
    FLA-5-17
    FLA-5-23    		51.5103120
    FLA-5-350-11
    FLA-5-350-17
    FLA-5-350-23    		51.89.43.8350
    FLA-6-11
    FLA-6-17
    FLA-6-23    		62.212.54.3120
    FLA-6-1000-11
    FLA-6-1000-17
    FLA-6-1000-23    		64.613.771000
    FLA-10-11
    FLA-10-17
    FLA-10-23    		102.516.75120
    FLA-30-11
    FLA-30-17
    FLA-30-23    		30236.15.1120
    flk_611FLK-1-11
    FLK-1-17
    FLK-1-23    		10.74.51.4120
    FLK-2-11
    FLK-2-17
    FLK-2-23    		20.95.51.5120
    FLK-6-11
    FLK-6-17
    FLK-6-23    		6111.22.2120
    FLK-10-11
    FLK-10-17
    FLK-10-23    		101.616.23.8120

    Each package contains 10 strain gauges.



    2-element 0°/90° Stacked type: FCA, Plane type: FCB(G.F. 2.1 approx.)

    Gauge patternTypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    (mm)    		Backing
    width
    (mm)    		Resistance (Ω)
    fca_211  FCA-1-11
    FCA-1-17
    FCA-1-23    		10.7Φ4.5120
    FCA-1-350-11
    FCA-1-350-17
    FCA-1-350-23    		11.6Φ8350
    FCA-2-11
    FCA-2-17
    FCA-2-23    		20.9Φ7120
    FCA-2-350-11
    FCA-2-350-17
    FCA-2-350-23    		21.9Φ9.5350
    FCA-3-11
    FCA-3-17
    FCA-3-23    		31.7Φ11120
    FCA-3-350-11
    FCA-3-350-17
    FCA-3-350-23    		32Φ10350
    FCA-5-11
    FCA-5-17
    FCA-5-23    		51.9Φ12120
    FCA-5-350-11
    FCA-5-350-17
    FCA-5-350-23    		51.8Φ10350
    FCA-6-11
    FCA-6-17
    FCA-6-23    		62.4Φ14120
    FCA-10-11
    FCA-10-17
    FCA-10-23    		102.5Φ17120

    Each package contains 10 strain gauges.



    3-element 0°/45°/90° Rosette Stacked type (G.F. 2.1 approx.)

    Gauge patternTypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    (mm)    		Backing
    width
    (mm)    		Resistance (Ω)
    fra_211  FRA-1-11
    FRA-1-17
    FRA-1-23    		10.7Φ4.5120
    FRA-1-350-11
    FRA-1-350-17
    FRA-1-350-23    		11.6Φ8350
    FRA-2-11
    FRA-2-17
    FRA-2-23    		20.9Φ7120
    FRA-2-350-11
    FRA-2-350-17
    FRA-2-350-23    		21.9Φ9.5350
    FRA-3-11
    FRA-3-17
    FRA-3-23    		31.7Φ11120
    FRA-3-350-11
    FRA-3-350-17
    FRA-3-350-23    		32Φ10350
    FRA-5-11
    FRA-5-17
    FRA-5-23    		51.9Φ12120
    FRA-5-350-11
    FRA-5-350-17
    FRA-5-350-23    		51.8Φ10350
    FRA-6-11
    FRA-6-17
    FRA-6-23    		62.4Φ14120
    FRA-10-11
    FRA-10-17
    FRA-10-23    		102.5Φ17120

    Each package contains 10 strain gauges.

  • GLASS/CERAMIC MATERIALS

    Gauge patternTypeGauge length
    (mm)    		Gauge width
    (mm)    		Backing length
    (mm)    		Backing width
    (mm)    		Resistance (Ω)
    Single-element (G.F. 2.1 approx.)fla_58 FLA-2-821.56.53120
    FLA-5-851.5103120
    90° 2-element Rosette (G.F. 2.1 approx.) Stacked typefca_28 FCA-2-820.9Φ7120
    FCA-5-851.9Φ12120
    45°/90° 3-element Rosette (G.F. 2.1 approx.) Stacked typefra_58 FRA-2-820.9Φ7120
    FRA-5-851.9Φ12120

    Each package contains 10 strain gauges.

  • RESIDUAL STRESS MEASUREMENT

    Gauge patternTypeGauge length (mm)Gauge width (mm)Backing length
    (mm)    		Backing width
    (mm)    		Resistance (Ω)Gauge center diameter (mm)
    fr_5FR-5-11
    FR-5-17
    FR-5-23    		51.5Φ12.0120-
    eubc_06EUBC-06-11
    EUBC-06-17
    EUBC-06-23    		0.60.7Φ2.4120-
    3-element (G.F.2.1 approx.)fras_211 FRAS-2-11
    FRAS-2-17
    FRAS-2-23    		21.199120Φ7.0
    frs_311FRS-2-11
    FRS-2-17
    FRS-2-23    		1.51.3Φ9.5120Φ5.14
    FRS-3-11
    FRS-3-17
    FRS-3-23    		32.6Φ17.5120Φ10.26

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

  • SHEARING STRAIN MEASUREMENT

    Gauge patternTypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    (mm)    		Backing
    width
    (mm)    		Resistance (Ω)
    flt_05aFLT-05A-11
    FLT-05A-17
    FLT-05A-23    		0.550.664.01.3120
    flt_05bFLT-05B-11
    FLT-05B-17
    FLT-05B-23    		0.550.664.01.3120

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

  • TORQUE MEASUREMENT

    Gauge patternTypeGauge length (mm)Gauge width (mm)Backing length
    (mm)    		Backing width
    (mm)    		Resistance (Ω)
    90° 2-element Rosette, Plane type (G.F. 2.1 approx.)fct_211 FCT-2-11
    FCT-2-17
    FCT-2-23    		21.58.76.5120
    FCT-2･350-11
    FCT-2･350-17
    FCT-2･350-23    		21.57.65.3350

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

  • 2-element 0°/90° plane type

    Gauge patternTypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    mm)    		Backing
    width
    (mm)    		Resistance (Ω)
    fcb_211FCB-2-11
    FCB-2-17
    FCB-2-23    		21.58.28120
    FCB-6-350-11
    FCB-6-350-17
    FCB-6-350-23    		621011.9350

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

  • STRESS CONCENTRATION MEASUREMENT

    Gauge
    pattern    		TypeGauge
    length
    (mm)    		Gauge
    width
    (mm)    		Backing
    length
    (mm)    		Backing
    width
    (mm)    		Resistance (Ω)Gauge
    leads    		gauge
    pitch
    5-element single axis X-axis direction (G.F.2.1 approx.)fxv_111002le FXV-1-11-002LE
    FXV-1-17-002LE
    FXV-1-23-002LE    		11.3512120Polyimide 2 cm pre-attached2 mm
    fbxv_0411005leFBXV-04-11-005LE0.41.35.47.4120Polyimide 5 cm pre-attached1 mm
    5-element single axis Y-axis direction (G.F.2.1 approx.)fyv_111002le FYV-1-11-002LE
    FYV-1-17-002LE
    FYV-1-23-002LE    		11.4512120Polyimide 2 cm pre-attached2 mm
    fbyv_0611005leFBYV-06-11-005LE0.60.85.37120Polyimide 5 cm pre-attached1 mm
    10-element 2 axes X-axis and Y-axis direction (G.F.2.1 approx.)fcv_111005le FCV-1-11-005LE
    FCV-1-17-005LE
    FCV-1-23-005LE    		11.47.512120Polyimide 5 cm pre-attached2 mm
    10-element single axis X-axis directionccfxx_1 CCFXX-1ccfxx_1l 11.54.516.4120-1.5 mm
    10-element single axis Y-axis directionccfyx_1 CCFYX-1ccfyx_1l 11.54.516.4120-1.5 mm

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

    Gauge patternTypeGauge length (mm)Gauge width (mm)Backing length (mm)Backing width (mm)Resistance (Ω)
    fbx_0411005le
    Polyimide 5 cm pre-attached    		FBX-04-11-005LE0.41.35.41120
    fby_0611005le
    Polyimide 5 cm pre-attached    		FBY-06-11-005LE0.60.85.31120
    flx_111002le
    Polyimide 2 cm pre-attached    		FLX-1-11-002LE
    FLX-1-17-002LE
    FLX-1-23-002LE    		11.352120

    Option -F (lead-free solder is used: with CE mark) available
    Each package contains 10 strain gauges.

  • Dedicated integral leadwire recommended for F series

    For general measurement  Single-element / two-element / three-element

    For general use

    ApplicationProduct nameLead wire codeApplicable temperature of leadwire (℃)Example of type name
    General use (without temperature change)Paralleled vinylLJB-20 to +80FLA-5-11-3LJB
    Paralleled vinylLJCFLA-5-11-3LJC
    General use3-wire paralleled vinylLJBT-20 to +80FLA-5-11-3LJBT
    3-wire paralleled vinylLJCTFLA-5-11-3LJCT
    Middle - high temperature3-wire paralleled vinylLXT-20 to +150FLA-5-11-3LXT
    Temperature-integrated3-wire paralleled vinylTLJBT-20 to +80FLA-5T-11-3TLJBT
    1-gauge 4-wirePolypropylene 4-wire paralleled (modular plug attached)LQM-20 to +100FLA-5-11-3LQM



    Special use (Torque, Stress concentration measurement)

    ApplicationProduct nameLead wire codeApplicable temperature of leadwire (℃)Example of type name
    General use (without temperature change)Paralleled vinylLJB/LJB-F-20 to +80FLA-5-11-3LJB
    General use3-wire paralleled vinylLJBT/LJBT-F-20 to +80FLA-5-11-3LJBT
    Middle - high temperature3-wire paralleled vinylLXT/LXT-F-20 to +150FLA-5-11-3LXT
    1-gauge 4-wirePolypropylene 4-wire paralleled (modular plug attached)LQM/LQM-F-20 to +100FLA-5-11-3LQM

  • Standard leadwire integrated strain gauge

    Strain gauges with paralleled vinyl leadwire or 3-wire paralleled vinyl lead wire are available as standard products for F series.

    Single-element

    Used leadwire: 0.11 mm2 Total resistance of leadwire per meter: 0.32 Ω

    fla_611_lead

    TypeGauge length (mm)Gauge width (mm)Backing length (mm)Backing width (mm)Resistance (Ω)Lead wire pre-attachedType name of lead wire preattached
    FLA-1-11
    FLA-1-17
    FLA-1-23    		11.352.5120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJC
    -3LJC
    -5LJC
    -3LJCT
    -5LJCT
    FLA-2-11
    FLA-2-17
    FLA-2-23    		21.56.53120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJC
    -3LJC
    -5LJC
    -3LJCT
    -5LJCT
    FLA-3-11
    FLA-3-17
    FLA-3-23    		31.78.83.5120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJC
    -3LJC
    -5LJC
    -3LJCT
    -5LJCT
    FLA-5-11
    FLA-5-17
    FLA-5-23    		51.5103120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJC
    -3LJC
    -5LJC
    -3LJCT
    -5LJCT
    FLA-6-11
    FLA-6-17
    FLA-6-23    		62.212.54.3120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJC
    -3LJC
    -5LJC
    -3LJCT
    -5LJCT

    Minimum order quantity is 10 gauges.



    2-element 0°/90° rosette

    Used leadwire: 0.08 mm2 Total resistance of leadwire per meter: 0.44 Ω

    fca_511_lead

    TypeGauge length
    (mm)    		Gauge
    width (mm)    		Backing (mm)Resistance (Ω)Lead wire pre-attachedType name of lead wire preattached
    FCA-1-11
    FCA-1-17
    FCA-1-23    		10.7Φ4.5120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FCA-2-11
    FCA-2-17
    FCA-2-23    		20.9Φ7120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FCA-3-11
    FCA-3-17
    FCA-3-23    		31.7Φ11120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FCA-5-11
    FCA-5-17
    FCA-5-23    		51.9Φ12120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FCA-6-11
    FCA-6-17
    FCA-6-23    		62.4Φ14120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FCA-10-11
    FCA-10-17
    FCA-10-23    		102.5Φ17120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT

    Minimum order quantity is 10 gauges.



    3-element 0°/45°/90° rosette

    Used leadwire: 0.08 mm2 Total resistance of leadwire per meter: 0.44 Ω

    FRA

    TypeGauge length
    (mm)    		Gauge
    width (mm)    		Backing (mm)Resistance (Ω)Lead wire pre-attachedType name of lead wire preattached
    FRA-1-11
    FRA-1-17
    FRA-1-23    		10.7Φ4.5120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FRA-2-11
    FRA-2-17
    FRA-2-23    		20.9Φ7120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FRA-3-11
    FRA-3-17
    FRA-3-23    		31.7Φ11120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FRA-5-11
    FRA-5-17
    FRA-5-23    		51.9Φ12120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FRA-6-11
    FRA-6-17
    FRA-6-23    		62.4Φ14120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT
    FRA-10-11
    FRA-10-17
    FRA-10-23    		102.5Φ17120Paralleled 1 m
    Paralleled 3 m
    Paralleled 5 m
    3-wire 3 m
    3-wire 5 m    		-1LJB
    -3LJB
    -5LJB
    -3LJBT
    -5LJBT

    Minimum order quantity is 10 gauges.

  •

icon
